12V IP68 waterproof 100 nodes RGB LED pixel light module string
- Buy 1000 for $11.95 each and save 8%
DC 12V working voltage, safe assurance
direct from factory, good price, made in Shenzhen of China, reliable quality with 2 years warranty
We are professional on LED light products, you can customize with special requirements. For any questions on product specifications, production time or shipping methods, please feel free to contact us
Specification
Working voltage: DC 12V
Working current: 25 mA
Working consumption: 0.3W
Working temperature: -40°C~ 60°C
Protection grade: IP68 waterproof
Wire color: red, green, blue, white is default, all black, all green is optional
LED type: 1 piece 8mm strawhat LED
LED quantity: 1 piece
Viewing angle: >90 degrees
Lifespan: MTBF>50000 hours
Feature
Programmable by DMX software
Conformal coating, PVC glue protection
IP68 waterproof protection
Easy installation (punching 12mm hole on metal panel)
100 pieces node
Applications
Meets the general lighting, environment such as: outdoors advertising, Christmas decoration
RGB pixels are digitally controllable lights you can set to any color, or animate.
Each RGB LED and controller chip is molded into a 'dot' of silicone, the dots are waterproof and rugged.
There are four flanges moulded in so that you can 'push' them into a 12mm drill hole in any material up to 1.5mm/0.06" thick.
They are typically used to make outdoor signs. Compared to our other 20mm LED dots.
These are diffused 8mm LEDs so they are not as bright but they color mix a little nicer.
A 4-conductor cable connects the pixels.
The pixels use 8mm diffused RGB LEDs with brightness of about 300 mcd per individual R/G/B LED.
